#include <rt.h>
Public Member Functions | |
| const char * | chName () const |
| void | zero () |
| void | comment (t_warnings &) |
 Public Member Functions inherited from module | |
| module () | |
| virtual | ~module () |
Data Fields | |
| realnum | wayin |
| realnum | wayout |
| realnum | fracin |
| realnum | DoubleTau |
| long int | ipxry |
| realnum | tauxry |
| bool | lgFstOn |
| int | nLineContShield |
| bool | lgElecScatEscape |
| realnum | dTauMase |
| bool | lgMaserSetDR |
| bool | lgMaserCapHit |
| long int | mas_species |
| long int | mas_ion |
| long int | mas_hi |
| long int | mas_lo |
| bool | lgStarkON |
|
inlinevirtual |
|
inlinevirtual |
|
virtual |
Implements module.
Definition at line 7 of file rt.cpp.
References DEBUG_ENTRY, DoubleTau, dTauMase, lgElecScatEscape, lgFstOn, lgMaserCapHit, and lgMaserSetDR.
| realnum t_rt::DoubleTau |
1 or two, set to double optical depth scale, set to 2 with double command default is 1
Definition at line 178 of file rt.h.
Referenced by ConvIterCheck(), ParseDoubleTau(), PrtComment(), RT_line_one_tau_reset(), RT_tau_init(), and zero().
| realnum t_rt::dTauMase |
dTauMase is smallest maser optical depth in atoms, set in RT_tau_inc for H, and in tauchn for heavy elements it is negative or zero
Definition at line 198 of file rt.h.
Referenced by radius_next(), RT_line_one_tauinc(), RT_tau_inc(), and zero().
| realnum t_rt::fracin |
fractin = wayin / (wayin+wayout) when outer defined, else zero
Definition at line 174 of file rt.h.
Referenced by esc_2side_base(), esc_CRDcore(), lincom(), lines(), PutLine(), RT_line_escape(), and RTesc_lya().
| long int t_rt::ipxry |
offset in continuum array for energy where x-ray opacity determined
Definition at line 181 of file rt.h.
Referenced by ContCreatePointers(), PrtFinal(), RT_tau_init(), and RT_tau_reset().
| bool t_rt::lgElecScatEscape |
include electron scattering escape for lines?
Definition at line 193 of file rt.h.
Referenced by ParseDont(), RT_DestProb(), RT_line_electron_scatter(), RTesc_lya(), and zero().
| bool t_rt::lgFstOn |
option to turn off fine structure line optical depths
Definition at line 187 of file rt.h.
Referenced by ContCreatePointers(), ParseDont(), and zero().
| bool t_rt::lgMaserCapHit |
flag set true in tauchn if maser cap ever hit, causes comment to be printed in prtComments
Definition at line 205 of file rt.h.
Referenced by IterStart(), PrtComment(), RT_line_one_tauinc(), and zero().
| bool t_rt::lgMaserSetDR |
set true in radius_next if maser ever sets zone thickness
Definition at line 201 of file rt.h.
Referenced by IterStart(), PrtComment(), radius_next(), and zero().
| bool t_rt::lgStarkON |
flag saying that stark broadening is enabled, set false with no stark
Definition at line 211 of file rt.h.
Referenced by InitDefaultsPreparse(), ParseDont(), and RT_stark().
| long int t_rt::mas_hi |
Definition at line 208 of file rt.h.
Referenced by radius_next(), RT_line_one_tauinc(), and RT_tau_inc().
| long int t_rt::mas_ion |
Definition at line 208 of file rt.h.
Referenced by radius_next(), RT_line_one_tauinc(), and RT_tau_inc().
| long int t_rt::mas_lo |
Definition at line 208 of file rt.h.
Referenced by radius_next(), RT_line_one_tauinc(), and RT_tau_inc().
| long int t_rt::mas_species |
these identify the species that had a major maser, for debugging
Definition at line 208 of file rt.h.
Referenced by radius_next(), RT_line_one_tauinc(), and RT_tau_inc().
| int t_rt::nLineContShield |
which type of line continuum shielding function should be used?
Definition at line 190 of file rt.h.
Referenced by InitDefaultsPreparse(), ParseSet(), and RT_continuum_shield_fcn_point().
| realnum t_rt::tauxry |
optical depth at this energy
Definition at line 184 of file rt.h.
Referenced by PrtFinal(), RT_tau_init(), and RT_tau_reset().
| realnum t_rt::wayin |
wayin - escape probability in inward direction
Definition at line 167 of file rt.h.
Referenced by esc_2side_base(), esc_CRDcore(), and RTesc_lya().
| realnum t_rt::wayout |
wayout - escape probability in outward direction =1 when outward optical depths unknown (touton .false.)
Definition at line 167 of file rt.h.
Referenced by esc_2side_base(), esc_CRDcore(), and RTesc_lya().
